Tektronix RSA5BUP Technical Reference

Specifications
Table 21: Spuri
ous response with signal a t center frequency (offset ≥400 kHz)
Span ≤ 25 MHz,
Swept Spans >
25 MHz
For Option B40
1
Swept Spans >
40 MHz
For Option B85, B125, B16x
1
40 MHz < Span ≤
160 MHz
For Op tio n
B85HD,
B125HD,
B16xHD
1
40 MHz < Span
≤ 165 MHz
Frequency Specifi cati
on
Typical Specificati
on
Typical Specificati
on
Typical Typical
1MHzto32MH
z(LF
band)
–80 dBc –85 dBc
–– –– –– –– ––
30 MHz to 3 GHz
–73 dBc –80 dBc –73 dBc –80 dBc –73 dBc –75 dBc –80 dBc
3GHzto6.2GHz
(RSA5106B)
–73 dBc –80 dBc –73 dBc –80 dBc –73 dBc –75 dBc –80 dBc
6.2 GHz to 15 GHz
(RSA511
5B)
–70 dBc –80 dBc –70 dBc –80 dBc –70 dBc –73 dBc –80 dBc
15 GHz to
26 GHz
(RSA5126B)
–66 dBc –76 dBc –66 dBc –76 dBc –66 dBc –73 dBc –76 dBc
1
Center frequency 150 MHz for O ptions B40/B85/B125/B16x.
Table 22: Spurious response with signal at center frequency (10 kHz ≤ offset ≤ 400 kHz)
Frequency Typical, (Span = 1 MHz)
1 MHz to 32 MHz (LF band)
–75 dBc
30MHzto3GHz
–75 dBc
3 GHz to 6.2 GHz (RSA5126B only)
–75 dBc
15 GHz to 26.5 GHz (RSA5126B only)
–68 dBc
Table 23: Spurious response with signal at input other than center frequency
Span
≤25 MHz,
swept spans
>25 M Hz
For Option
B40
1
Span
≤40 MHz,
swept spans
>40 MHz
For Option
B85
1
40 MHz
<Span≤
85 MHz
For Option
B125, B16x
12
85 MHz < Span
≤ 165 MHz
For Option
B85HD,
B125HD,
B16xHD
1
40 MHz < Span
≤ 165 MHz
Frequency Typical Typical Typical Typical Typical
1 M Hz to 32 MHz (LF band)
–80 dBc
–– –– –– ––
30MHzto3GHz
–80 dBc –80 dBc –76 dBc –73 dBc –80 dBc
3 GHz to 6.2 G Hz (RSA5106B)
–80 dBc –80 dBc –76 dBc –73 dBc –80 dBc
6.2 GHz to 15 GHz (RSA 5115B)
–80 dBc –80 dBc –73 dBc –73 dBc –80 dBc
15 GHz to 26.5 GHz (RSA5126B)
–76 dBc –76 dBc –73 dBc –73 dBc –76 dBc
1
Center frequency 150 MHz for O ptions B40/B85/B125/B16x.
2
-70 dBc for input signals 20 MHz above or below instrument center frequency.
3
Mean of performance measured over a sample interval.
RSA5100B Series Technical Reference 27
