Tektronix RSA5BUP Technical Reference

Specifications
Table 17: Pulse measurements, typical (cont.)
Characteristic Description
Pulse-to-Pulse carrier phase,
NON-Chirped Pulse, 95% confidence, typical
60 MHz BW
1
25 MHz BW
2
2 GHz ±0.3° ±0.2°
10 GHz ±0.5° ±0.5°
20 GHz ±0.8° ±0.8°
85 MHz BW
1
40 MHz BW
2
2 GHz ±0.3° ±0.2°
10 GHz ±0.5° ±0.5°
20 GHz ±0.8° ±0.8°
125 MHz BW
1
2GHz ±0.3°
10 GHz ±0.5°
20 GHz ±0.8°
160 MHz BW
1
2GHz ±0.3°
10 GHz ±0.5°
20 GHz ±0.8°
Pulse-to-Pulse Delta Frequency,
NON-Chirped Pulse, 95% confidence,
typical
60 MHz BW
3
25 MHz BW
4
2GHz
±1.5 kHz ±0.5 kHz
10 GHz
±3 kHz ±1.5 kHz
20 GHz
±4 kHz ±2 kHz
85 MHz BW
3
40 MHz BW
4
2GHz
±2 kHz ±1 kHz
10 GHz
±3 kHz ±2 kHz
20 GHz
±4 kHz ±3 kHz
125, 160 MHz BW
3
2GHz
±4.5 kHz
10 GHz
±6 kHz
20 GHz
±8 kHz
18 RSA5100B Series Technical Reference
