Magnitude cursors Frequency cursors
You can also take a frequency measurement without using the cursors. To do so,
turn the Horizontal Position knob to position a frequency component on the
center graticule line and read the frequency at the top right of the display.
FFT
60 TBS1000B and TBS1000B-EDU Series Oscilloscopes User Manual
