Fig. &
index
number
Tektronix part number Serial no.
effective
Serial no.
discont'd
Qty
1
Name & description
-10 348-1909-xx 2 FOOT REAR; SAFETY CONTROLLED
-11 348-2209-xx 2 FOOT, FRONT CABINET, HINGED, SAFETY CONTROLLED
-12 214-5148-xx 2 SPRING FRONT FOOT
-13 131-6643-xx 4 CONTACT, ELECTRICAL
-14 220-0265-xx 3 NUT, PLAIN, HEX; 0.5-28 X 0.625 HEX, BRS, NKL PL
-15 210-1039-xx 3 WASHER, LOCK INTERNAL TOOTH
-16 407-5915-xx 1 BRACKET, REAR BNC IN MAIN BOARD
-17 211-1273-xx 6 SCREW, PT; K35-1.57, PAN HEAD, STL, ZNPL, T-15
-18 870-1175-xx 1 CIRCUIT BOARD ASSY; MAIN B2 BOARD
-19 174-6699-xx 1 CABLE CONNECTION, FRONT- PANEL & MAIN BOARD
-20 253-0571-xx 1 THERMAL INTERFACE MATERIAL SQUARE, 27X27MM
-21 253-0570-xx 1 THERMAL INTERFACE MATERIAL SQUARE, 15X15MM
-22 146-0148-xx 1
4
BATTERY, DRY: 3 VOLT, 150MAH, LITHIUM, LEADED
BUTTON CELL, SAFETY CONTROLLED
-23 1
-N/A 119-8771-xx 1
5
WIFI USB DONGLE FOR TBS
Replaceable parts
30 TBS2000B Series Service Manual
