Replaceable Parts List
Mechanical Parts List
10Ć2
Modules can be serviced by selecting one of the following
three options. Contact your local Tektronix service center or
representative for repair assistance.
Module Exchange. %" % $ %" "
"!" " " ! !% ! #
" ! ! !% ! !
"! ! " $ &&& $!
Module Repair and Return. " % %" " ! " !
# # # !" ! ! %"
New Modules. " % " ! " ! #%
! ! !
Using the Replaceable Parts List
This section contains a list of the mechanical and/or electrical components that
are replaceable for the TDS 520A, 524A, 540A, & 544A. Use this list to identify
and order replacement parts. The following table describes each column in the
parts list.
Parts List Column Descriptions
Column Column Name Description
1 Figure & Index Number Items in this section are referenced by figure and index numbers to the exploded view illustrations
that follow.
2 Tektronix Part Number Use this part number when ordering replacement parts from Tektronix.
3 and 4 Serial Number Column three indicates the serial number at which the part was first effective. Column four
indicates the serial number at which the part was discontinued. No entries indicates the part is
good for all serial numbers.
5 Qty This indicates the quantity of parts used.
6 Name & Description An item name is separated from the description by a colon (:). Because of space limitations, an
item name may sometimes appear as incomplete. Use the U.S. Federal Catalog handbook H6-1
for further item name identification.
7 Mfr. Code This indicates the code of the actual manufacturer of the part.
8 Mfr. Part Number This indicates the actual manufacturer’s or vendor’s part number.
Abbreviations conform to American National Standard ANSI
Y1.1-1972.
The table titled Manufacturers Cross Index shows codes,
names, and addresses of manufacturers or vendors of
components listed in the parts list.
Module Servicing
Abbreviations
Mfr. Code to Manufacturer
Cross Index
