Nominal Traits
Specifications
1Ć12
TableĂ1Ć6:ăNominal Traits Ċ Interfaces, Output Ports, and Power Fuse
Name Description
Interface, GPIB GPIB interface complies with IEEE Std 488-1987
Interface, RSĆ232 RSĆ232 interface complies with EIA/TIA 574 (talk only)
(optional, as option 13, on TDS 520A and 540A)
Interface, Centronics Centronics interface complies with Centronics interface standard
C332Ć44 Feb 1977, REV A
(optional, as option 13, on TDS 520A and 540A)
Interface, Video VGA video output with levels that comply with ANSI R5343A stanĆ
dard. DBĆ15 connector.
Logic Polarity for MainĆ and DelayedĆ
Trigger Outputs
Negative TRUE. High to low transition indicates the trigger occurred.
Fuse Rating Either of two fuses
1
may be used: a .25I × 1.25I (UL 198.6, 3AG):
6 A FAST, 250 V, or a 5 mm × 20 mm, (IEC 127): 5 A (T), 250ĂV.
1 Each fuse type requires its own fuse cap.
