Warranted Characteristics
Specifications
1Ć16
TableĂ1Ć8:ăWarranted Characteristics Ċ Signal Acquisition System (Cont.)
Name Description
Analog Bandwidth, DCĆ50ĂW Coupled
or DCĆ1 MW Coupled
Volts/Div
5 mV/div - 10 V/div
2 mV/div - 4.98 mV/div
1 mV/div - 1.99 mV/div
Bandwidth
4
DC - 500 MHz
DC - 350 MHz
DC - 250 MHz
Cross Talk (Channel Isolation) w100:1 at 100 MHz and w30:1 at the derated bandwidth for any two
channels having equal volts/division settings
Input Impedance, DCĆ1ĂMW Coupled 1MW ± 0.5% in parallel with 10 pF ±2 pF
Input Impedance, DCĆ50ĂW Coupled
50 W ± 1% with VSWR v1.3:1 from DC - 500 MHz
Input Voltage, Maximum, DCĆ1ĂMW,
ACĆ1ĂMW, or GND Coupled
±400 V (DC + peak AC); derate at 20 dB/decade above 1 MHz
Input Voltage, Maximum, DCĆ50ĂW or
ACĆ50ĂW Coupled
5V
RMS
, with peaks v ±30 V
Lower Frequency Limit, AC Coupled v10 Hz when AC-1ĂMW Coupled; v200 kHz when AC - 50ĂW
Coupled
5
1 Net Offset = Offset - (Position Volts/Div). Net Offset is the nominal voltage level at the center of the AĆD converter dynamic
range. Offset Accuracy is the accuracy of this Voltage level.
2 The samples must be acquired under the same setup and ambient conditions.
3 To ensure the most accurate measurements possible, run an SPC calibration first. When using the oscilloscope at a Volts/Div
setting v5 mV/div, an SPC calibration should be run once per week to ensure that instrument performance levels meet specificaĆ
tions.
4 The limits given are for the ambient temperature range of 0_ĂCto+30_ĂC. Reduce the upper bandwidth frequencies by 2.5 MHz
for each _ĂC above +30_ĂC.
5 The AC Coupled Lower Frequency Limits are reduced by a factor of 10 when 10X, passive probes are used.
TableĂ1Ć9:ăWarranted Characteristics Ċ Time Base System
Name Description
Accuracy, Long Term Sample Rate
and Delay Time
±25 ppm over any w1 ms interval
