Probe Selection
TDS 620A, 640A, & 644A User Manual
3Ć117
Table 3-7 lists TDS 600A compatible probes classified by type.
Table 3-7: TDS 600A Compatible Probes
Probe Type
Tektronix Model Description
Passive, high impedance
voltage
P6139A (std.)
P6101A
10X, 500 MHz
1X, 15 MHz
Passive, SMD P6563AS 20X, 500 MHz
Passive, low impedance Z
O
P6156 10X, 3.5 GHz, for 50
W
inputs (1X, 20X, 100X optional)
Passive, high voltage P6009
P6015A
100X,1.5 kV, DC + peak AC
1000X, 20 kV, DC + peak AC
Active, high speed voltage P6204 DC to 1 GHz FET. DC Offset capability (requires Tektro-
nix 1103 TekProbe Power Supply for offset capability)
Active, high speed voltage P6205 DC to 750 MHz FET
Active, differential voltage P6046 1X/10X, DC to 100 MHz
Active, fixtured voltage A6501
P6501
Opt. 02
Buffer Amplifier, 1 GHz, 1 M
W
10X
Microprobe with TekProbe Power Cable, 750 MHz,
1 M
W
10X
Current AM 503S
AM 503S
Opt. 03
P6021
P6022
CT-1/CT-2
CT-4
AC/DC. Uses A6302 Current Probe.
AC/DC. Uses A6303 Current Probe.
AC. 120 Hz to 60 MHz.
AC. 935 kHz to 120 MHz.
Designed for permanent or semi-
permanent in-circuit installation
CT-1: 25 kHz to 1 GHz, 50
W
input
CT-2: 1.2 kHz to 200 MHz, 50
W
input
Current Transformer for use with
AM 503S and P6021. Peak pulse
1 kA, 0.5 Hz to 20 MHz with AM 503S
Logic Word Trigger P6408 16 channel, one qualifier channel, TTL compatible, +5 V
power supply required
Optical
(Opto-Electronic Converters)
P6701A
P6703A
P6711
P6713
500 to 950 nm, DC to 850 MHz, 1 V/mW
1100 to 1700 nm, DC to 1 GHz, 1 V/mW
500 to 950 nm, DC to 250 MHz, 5 V/mW
1100 to 1700 nm, DC to 300 MHz, 5 V/mW
Time-to-Voltage Converter TVC 501 Time delay, pulse width and period measurements
