Appendix A: Options and Accessories
Appendices
AĆ4
constant, or a ratio calibration technique. The calibration is in compliance with
US MIL–STD–45662A. This option also includes a test data report for the
instrument.
The following standard accessories are included with the digitizing oscillo-
scope:
Table A-2: Standard Accessories
Accessory
Part Number
User Manual 070–8710–01
Programmer Manual 070–8709–02
Reference 070–8711–02
Performance Verification 070–8712–01
Front Cover 200–3696–00
U.S. Power Cord 161–0230–01
Probes, TDS 540A & TDS 544A (quantity four),
10X Passive
TDS 520A & TDS 524A (quantity two),
10X Passive
P6139A (single unit)
Probe Accessories
These are accessories to the standard probe listed previously (P6139A).
Except for the probe-tip-to-circuit board adapter, they can also be ordered
separately.
Table A-3: Probe Accessories
Accessory
Part Number
Retractable Hook Tip 013–0107–06
Body Shell, tip cover 204–1049–00
Probe-Tip-to-Circuit Board Adapter
(quantity two standard, optionally available in pack-
age of 25 as 131–5031–00)
No customer order-
able part number for
double unit
Six-inch Slip-On Ground Lead 196–3113–02
Low Inductance Ground Lead 195–4240–00
Marker Rings Set (quantity eighteen rings which in-
cludes two each of nine colors)
016–0633–00
Ground Collar 343–1003–01
Standard
Accessories
