Tektronix TDS 410A - Table 2-25: Offset Ranges for the TDS 4 XXA, 54 XA, 6 XXA, & 7 XXA; Table 2-26: Offset Ranges for the TDS 520 A & 524 A (Aux 1 & Aux 2) Using a 1 X Probe

Command Descriptions
TDS Family Oscilloscope Programmer Manual
2–65
Table 2–25: Offset Ranges for the TDS 4XXA, 54XA, 6XXA, & 7XXA (All Channels)
and the TDS 520A & 524A (Channel 1 & Channel 2) using a 1x Probe
CH<x>:SCAle OFFSet Range
1 mV/div – 99.5 mV/div ±1 V
100 mV/div – 995 mV/div ±10 V
1 V/div – 10 V/div ±100 V
Table 2–26: Offset Ranges for the TDS 520A & 524A (Aux 1 & Aux 2) using a 1x
Probe
CH<x>:SCAle OFFSet Range
50 mV/div & 100 mV/div ±.5 V
500 mV/div & 1 V/div ±5.0 V
5 V/div & 10 V/div ±50 V
CH1:OFFSET 0.5E+00
lowers the channel 1 displayed waveform by 0.5 volts.
CH1:OFFSET?
might return 500.0E-3, indicating that the current channel 1 offset is 0.5 volts.
CH<x>:POSition
Sets or queries the vertical position of the specified channel. The position value
is applied to the signal before digitization. This is equivalent to setting Position
in the Vertical menu or adjusting the front-panel Vertical Position knob.
Vertical
CH<x>:OFFSet
CH<x>:POSition <NR3>
CH<x>:POSition?
Examples
Group
Related Commands
Syntax
