Tektronix TDS 420A Service Manual

Adjustment Procedures
5-6
TDS 420A, TDS 430A & TDS 460A Service Manual
Table 5- 3: Test Equipment, Fixtures, and Supplies (Cont.)
Item Number and
Description
PurposeExampleMinimum Requirements
14. Generator, Leveled Sine
Wave, high-frequency
250 MHz to 500 MHz; Variable
amplitude from 5 mV to 4 V
p-p
into 50 Ω; harmonic content:
2
nd
harmonic down --30 dB from
fundamental; all others
down --40 dB
Rohde & Schwarz SMY Sine
Wave Generator, Rohde &
Schwarz URV 35 Level Meter
with NRV--Z8 Power Sensor,
and RVZ Power Splitter, (or,
optionally, TEKTRONIX
SG 504
1
Leveled Sine Wave
Generator with its leveling head
or a TEKTRONIX SG 5030
2
Programmable Leveled Sine
Wave Generator with its level-
ing head)
Softw are based adjustments
15. Generator, Pulse High amplitude pulse with
variable amplitude of 60 V
to 100 V
Wavetek 9100 with options 100
and 250 (or, optionally, TEK-
TRONIX PG 506A
Calibration Generator
1
)
Softw are based adjustments
and probe adjustment
16. Head, Pulse Generator TEKTRONIX 067-0681-01 TEKTRONIX 067-0681-01
Tunnel Diode Pulser
Probe adjustment
17. Photometer 0.1 to 200 Footlamberts
(0.343 to 686 Candelas)
Tektronix J17 Photometer with
J1803 Luminance Probe
Contrast adjustment
1
Requires a TM 500 or TM5000 Series Power Module Mainframe.
2
Requires a TM5000 Series Power Module Mainframe.
