Troubleshooting
6-90
TDS 420A, TDS 430A & TDS 460A Service Manual
J440
Figure 6- 40: A26 Monitor Connector J440
J7
Pin 1
J4
Pin 1
Figure 6- 41: A07 Auxiliary Power Connectors J4 and J7
