Options and Accessories
7-4
TDS 420A, TDS 430A & TDS 460A Service Manual
Table 7- 4: Compatible Probes (Cont.)
Probe Type DescriptionTektronix Model
Passive, low impedance Zo P6156 10X, 3.5 GHz, for 50 Ω inputs (1X, 20X, 100X optional)
Passive, high voltage P5100
P6015A
100X, 2.5 kV, DC + peak AC
1000X, 20 kV, DC + peak AC
Active, high speed voltage P6243
P6204
DC to 1 GHz FET, TekProbe powered
DC to 1 GHz FET, DC Offset capability (requires Tektronix 1103
TekProbe Power Supply for offset capability)
Active, differential voltage P6046
P5205
1X/10X, 250 V, DC to 100 M Hz
50X/500X, 1300 V, DC to 100 MHz
Current AM 503S
AM 503S Opt. 03
AM 503S Opt. 05
TCP202
P6021
P6022
CT-1/CT-2
CT-4
AC/DC, Uses DC to 50 MHz A6302 Current Probe
AC/DC, Uses DC to 15 MHz A6303 Current Probe
AC/DC, Uses DC to 100 MHz A6312 Current Probe
AC/DC, DC to 50 M Hz, TekProbe powered
AC, 120 Hz to 60 MHz
AC, 935 kHz to 120 MHz
Designed for permanent or semi-permanent in-circuit installation
CT-1: 25 kHz to 1 GHz, 50 Ω input
CT-2: 1.2 kHz to 200 MHz, 50 Ω input
Current Transformer for use with AM 503S and P6021. Peak pulse
1 kA, 0.5 Hz to 20 MHz with AM 503S
Logic Word Trigger P6408 16 channel, one qualifier channel, TTL compatible, +5 V power
supply required
Optical (Opto-Electric Converters) P6701A
P6703A
P6711
P6713
500 to 950 nm, DC to 850 MHz, 1 V/mW
1100 to 1700 nm, DC to 1 GHz, 1 V/mW
500 to 950 nm, DC to 250 MHz, 5 V/mW
1100 to 1700 nm, DC to 300 MHz, 5 V/mW
