Tektronix TDS 420A Service Manual

Performance Tests
TDS 420A, TDS 430A & TDS 460A Service Manual
4-17
Table 4- 1: Test Equipment (Cont.)
Item Number and
Description
PurposeExampleMinimum Requirements
13. Splitter, Power Frequency range: DC to 1 GHz.
Tracking: >2.0%
Rohde & Schwarz RVZ Checking Analog Bandwidth
14. Generator, Function Frequency range 5 MHz to 10 MHz.
Square wave transition time ≤25 ns.
Amplitude range: 0 t o 10 V
p-p
into 50Ω
Tektronix CFG280 Checking External Clock
15. Adapter (four required) Male N to female BNC Tektronix 103--0045--00 Checking Analog Bandwidth
16. Adapter Female N to male BNC Tektronix 103--0058--00 Checking Analog Bandwidth
17. Probe, 10X included with
this oscilloscope
A P6138A probe Tektronix P6138A Signal Interconnection
18. Generator, Video Signal Provides NTSC compatible outputs Tektronix TSG 1001 Checking Video
Trigger Sensitivity
1
If available, items 11, 12, 13, and 15 can be replaced by a Tektronix SG 503 and SG 504. If available, a TG 501A may be
used to check Sample-rate and Delay-time Accuracy. (A TM 500 or TM 5000 Series Power Module Mainframe is required.)
If using a TG 501A, you m ay also need a 2X attenuator (50 Ω BNC), Tektronix part number 011-0069-02.
