TDS2CMA Communications Module
132
TDS1000/2000-Series Digital Oscilloscope User Manual
Option Settings Comments
Layout Portrait, Landscape Printer output orientation
Format Thinkjet, Deskjet, Laser Jet,
Bubble Jet, Epson, BMP, PCX,
TIFF, RLE, EPSIMAGE,
DPU411, DPU412, DPU3445
Type of device connected to
the communications port
Port Centronics, RS-232, GPIB C ommunications port used to
connect the oscilloscope to a
printer or computer
Ink Saver* On, Off On prints the screen data on a
white background
Abort
Printing
Stops sending screen data to
theprinter
*
Only for TDS2000-series oscilloscopes.
NOTE. If you use the R S-232 or GPIB port, you also need to set up
the parameters for the port appropriately for your printer.
