Operating Basics
The front panel is divided into easy-to-use functional areas. This
chapter provides you with a quick overvie w of the controls and the
information displayed on the screen. T he ne xt figure shows the front
panels for 2-channel and 4-channel models.
2-channel models
4-channel models
