Application Examples
42
TDS1000/2000-Series Digital Oscilloscope User Manual
Taking Simple Measurements
You need to see a signal in a circuit, but you do not know the
amplitude or frequency of the signal. You want to quickly display the
signal and measure the frequency, period, and peak-to-peak
amplitude.
CH 1
Using Autoset
To quickly display a signal, follow these steps:
1. Push the CH 1 MENU button and set the Probe option
attenuation to 10X.
2. Set the switch to 10X on the P2200 probe.
