Getting Started
6
TDS1000/2000-Series Digital Oscilloscope User Manual
Probe Safety
A guard around the probe body provides a finger barrier for
protection from electric shock.
Finger guard
WARNING. To avoid electric shock when using the probe, keep fingers
behind the guard on t he probe body.
To avoid electric shock while using the probe, do not touch metallic
portions of the probe head while it is connected to a voltage source.
Connect the probe to the oscilloscope and connect the ground
terminal to ground before you t ake any measurements.
