TDS2CMA Communications Module
148
TDS1000/2000-Series Digital Oscilloscope User Manual
GPIB Network Conventions
To achieve a high data t ransfer rate, the physical distance between
devices and the number of devices on the bus are limited. When you
create the GPIB network, follow these guide lines:
H Connect the GPIB devices in a star, linear, or combina tion
star/linear network.
CAUTION. Do not use loop or parallel networks.
