Appendix A: Specificati ons
TDS1000/2000-Series Digital Oscilloscope User Manual
161
Oscilloscope Specifications (Cont.)
Measurements
Cursors
Voltage difference between cursors (∆V)
Time difference between cursors (∆T)
Reciprocal of ∆TinHertz(1/∆T)
Automatic
Measurements
Frequency, Period, Mean, Pk-Pk, Cycle RMS, Min, Max, Rise
Time, Fall Time, Pos Width, Neg Width
Oscilloscope General Specifications
Display
Display Type 5.7 in. (145 mm) ( diagonal liquid crystal
Display Resolution 320 horizontal by 240 vertical pixels
Display Contrast Adjustable, temperature compensated
Backlight Intensity,
typical
65 cd/m
2
Probe Compensator Output
Output Voltage, typi-
cal
5Vinto≥ 1MΩ load
Frequency, typical 1kHz
Power Source
Source Voltage 100 -- 120 VAC
RMS
( 10%) from 45 Hz through 440 Hz, CAT II
120 -- 240 VAC
RMS
( 10%) from 45 Hz through 66 Hz, CAT II
Power Consumption Less than 30 W
Fuse 1 A, T rating, 250 V
