Settings to avoid aliasing in Sample mode (Cont.)
Time base
(SEC/DIV)
Samples per
second
Maximum
frequency
component
1.0 ms 250.0 kS/s 125.0 kHz
2.5 ms 100.0 kS/s 50.0 kHz
5.0 ms 50.0 kS/s 25.0 kHz
10.0 ms 25.0 kS/s 12.5 kHz
25.0 ms 10.0 kS/s 5.0 kH z
50.0 ms 5.0 kS/s 2.5 kHz
100.0 ms 2.5 kS/s 1.25 kHz
250.0 ms 1.0 kS/s 500.0 Hz
500.0 ms 500.0 S/s 250.0 Hz
1.0 s 250.0 S/s 125.0 Hz
2.5 s 100.0 S/s 50.0 Hz
5.0 s 50.0 S/s 25.0 Hz
10.0 s 25.0 S/s 12.5 Hz
25.0 s 10.0 S/s 5.0 Hz
50.0 s 5.0 S/s 2.5 Hz
