Reference
80
TDS1000/2000-Series Digital Oscilloscope User Manual
The Autoset function examines all channels for signals and displays
corresponding waveforms.
Autoset determines the trigger source based on the fol lowing
conditions:
H If multiple channels have signals, channel with the lowest
frequency signal
H No signals found, the lowest-numbered channel displayed when
Autoset was invoked
H No signals found and no channels displayed, oscilloscope
displays and uses channel 1
