Tektronix TDS3000 Series - Figure 6-22: Remove Front-Panel Keypads

Maintenance
TDS3000 Series Service Manual
6–33
6. Remove the front-panel and bezel button keypads by lifting them away from
the front panel. Do not touch the keypad contacts or place them on a
contaminated surface. See Figure 6–22.
Front panel keypad
Bezel keypad
Figure 6–22: Remove front-panel keypads
