Tektronix TDS3000 Series Service Manual

Specifications
TDS3000 Series Service Manual
1–3
Table 1–1: Specifications (cont.)
Vertical
Number of channels
TDS3012, TDS3032, TDS3052 TDS3014, TDS3034, TDS3054
2 plus external trigger input 4
Digitizers 9-bit resolution, separate digitizers for each channel sample
simultaneously
SCALE Range
(at BNC)
1 M W 50 W
(at BNC)
1 mV/div to 10 V/div 1mV/div to 1 V/div
Fine SCALE Adjustable with ≥ 1% resolution
Polarity Normal and Invert
Position range ±5 divisions
n
Analog bandwidth,
50 W
(also typical at 1 M W
Bandwidth limit set to Full, operating ambient ≤30 °C, derate 1%/°C
above 30 °C
(also typical at 1 M
W
with standard probe)
Scale range
TDS3012
TDS3014
TDS3032
TDS3034
TDS3052
TDS3054
5 mV/div to
1 V/div
100 MHz 300 MHz 500 MHz
2 mV/div to
4.98 mV/div
100 MHz 250 MHz 300 MHz
1 mV/div to
1.99 mV/div
90 MHz 150 MHz 175 MHz
Calculated rise
time, typical
— 3.5 ns 1.2 ns 0.7 ns
Analog bandwidth
limit, typical
Selectable between 20 MHz, 150 MHz (not available on TDS3012 or
TDS3014), or Full
Lower frequency limit,
AC coupled, typical
7 Hz for 1 M W , reduced by a factor of ten when using a 10X passive
probe; 140 kHz for 50 W
