Performance Verification
4–10
TDS3000 Series Service Manual
19. Set the output frequency of the leveled sine wave generator to the frequency
shown in the table below.
Oscilloscope model Frequency
TDS3012, TDS3014 100 MHz
TDS3032, TDS3034 300 MHz
TDS3052, TDS3054 500 MHz
20. Set the output amplitude of the leveled sine wave generator so the peak-to-
peak measurement is approximately 500 mV.
21. Push the SET TO 50% button. Adjust the trigger LEVEL as necessary and
then verify that triggering is stable.
22. Push the trigger MENU button.
23. Push the Slope screen button and select the \ (falling) slope.
24. Push the SET TO 50% button. Adjust the trigger LEVEL as necessary and
then verify that triggering is stable.
25. Push the Slope screen button and select the / (rising) slope.
26. Push the waveform off
button.
27. Repeat steps 11 through 26 for each channel of the oscilloscope (not
including the external trigger input on some models).
