Tektronix TDS3032B Reference

39
Bottom DescriptionSide
Position
Vertical Posi-
tion
Enables numerical vertical
position adjustment.
Set to 0 divs Sets vertical position to center
screen.
Offset
Vertical Offset Enables vertical offset adjust-
ment with the general purpose
knob.
Set to 0 V Sets vertical offset to 0 V.
Probe Setup
Voltage Probe
Use to set probe gain or attenu-
Current Probe
ation for probes that do not
have the TekProbe II interface.
Deskew Use to adjust the time skew
correction for each probe.
Set to 0 Use to set probe skew correc-
tion to zero.
40
Math Menu
Bottom Side Description
Dual Wfm
Math
Set 1st Source
to
Selects the first source wave-
form.
Set Operator
to
Selects the math operator: +, –,
, or B
Set 2nd
Source to
Selects the second source
waveform.
Ref Menu
Bottom Side Description
Ref 1
Save Ch1 to
Ref1
Saves channel 1 to reference
waveform Ref 1.
Save Ch2 to
Ref1
Saves channel 2 to reference
waveform Ref 1.
Save Ch3 to
Ref1
Saves channel 3 to reference
waveform Ref 1.
Save Ch4 to
Ref1
Saves channel 4 to reference
waveform Ref 1.
Save Math to
Ref1
Saves the math waveform to
reference waveform Ref 1.
Ref 2
Ref 3
Ref 4
Identical settings for reference waveforms Ref 2,
Ref 3, and Ref 4.
