TDS3000B Series Service Manual
4-1
Performance Verification
This chapter contains performance verification procedures for the specifications
marked with the n symbol. The following equipment, or a suitable equivalent,
is required to complete these procedures.
Description
Minimum
requirements
Examples
DC Voltage Source 3mVto4V,±0.1% accuracy Wavetek 9500
Leveled Sine Wave Generator 50 kHz to 600 MHz, ±4%
amplitude accuracy
Oscilloscope Calibrator with
two 9510 Output Modules
Time Mark Generator 10 ms period, ±5 ppm accu-
racy
50 Ω feedthrough
termination
BNC connectors Tektronix part number
011-0099-00
You may need additional cables and adapters, depending on the actual test
equipment you use.
These procedures cover all TDS3000B oscilloscope models. Please disregard
checks that do not apply to the specific m odel you are testing.
Photocopy the test record on the next two pages and use them to record the
performance test results for your oscilloscope.
NOTE. Successful completion of the performance verification procedure does not
update the instrument Calibration Due date and time.
Successful completion of the Adjustment Procedure in Section 5 does automati-
cally update the instrument Calibration Due date and time.
