Performance Verification
TDS3000B Series Service Manual
4-11
18. Set the vertical SCALE to 500 mV/div.
19. Set the output frequency of the leveled sine wave generator to the frequency
shown in the table below.
Oscilloscope model Frequency
TDS301xB 100 MHz
TDS302xB 200 MHz
TDS303xB 300 MHz
TDS304xB 400 MHz
TDS305xB 500 MHz
TDS306xB 600 MHz
20. Set the output amplitude of the l eveled sine wave generator so that the
oscilloscope peak-to-peak measurement is approximately 2.5 V. Note the
generator output amplitude setting.
21. Set the leveled sine wave generator output amplitude to one-fifth of the
output amplitude value that was set in step 20.
22. Push the SET TO 50% button. Adjust the trigger LEVEL as necessary and
then verify that triggering is stable.
23. Push the trigger MENU button.
24. Push the Slope screen button and select the \ (falling) slope.
25. Push the SET TO 50% button. Adjust the trigger LEVEL as necessary and
then verify that triggering is stable.
26. Push the Slope screen button and select the /(rising)slope.
27. Push the waveform off
button.
28. Repeat steps 11 through 27 for each channel of the oscilloscope (not
including the external t rigger input).
