Maintenance
4-32
TDS3000C Series S ervice Manual
6. Remove the front-panel and bezel button keypads by lifting them away from
the front panel. Do not touch the keypad contacts or place them on a
contaminated surface. See Figure 4--18.
Front panel keypad
Bezel keypad
Figure 4- 18: Remove front-panel keypads
