Tektronix TDS6000 Series Service Manual

Removal and Installation Procedures
TDS7104 & TDS7054 Service Manual
6-- 13
Left side trim
Front panel trim
Acquisition trim
Right side trim
T-15 T orx
screw (3)
T-15 Torx screw (4)
Top cover trim
T-15 Torx screw (2)
Carrying handle
Snap stud (4)
To remove the trim ring, slide the flat
end of a soldering aid into the side
slot on the trim ring. Press in, then
lift up to hook it underneath, then
pry up.
Soldering aid
Figure 6--3: Trim removal
