TDS7104 & TDS7054 Service Manual
1-1
Specifications
This chapter contains the specifications for the TDS7000 series Digital Phosphor
Oscilloscopes. All specifications are guaranteed unless labeled “typical.” Typical
specifications are provided for your convenience but are not guaranteed.
Specifications that are marked with the n symbol are checked in chapter four,
Performance Verification.
All specifications apply to all models unless noted otherwise. To meet specifica-
tions, the following conditions must be met:
H The instrument must have been calibrated in an ambient temperature
between 20 °C and 30 °C(68°F and 86 °F).
H The instrument must be operating within the environmental limits listed in
Table 1--10 on page 1--20.
H The instrument must be powered from a source that meets the specifications
listed in Table 1--8 on page 1--18.
H The instrument must have been operating continuously for at least 20
minutes within the specified operating temperature range.
H You must perform the Signal Path Compensation procedure after the
20-minute warm-up period, and if the ambient temperature changes more
than 5 °C(41°F), repeat the procedure. See Run the signal-path compensa-
tion routine on page 4--6 for instructions to perform this procedure.
Product and Feature Description
Your oscilloscope is shown in Table 1--1.
Table 1- 1: TDS7000 models
Model
Number of
channels
Bandwidth
Maximum sample
rate (real time)
TDS7054 4 500 M Hz 5 GS/ s
TDS7104 4 1GHz 10 GS/s
