Removal and Installation Procedures
TDS7104 & TDS7054 Service Manual
6-- 15
1. Remove the left and right covers: See Figures 6--5 and 6--6, on pages 6--16
and 6--17.
H Trim (all)
H Bottom cover
2. Orient the oscilloscope: Set the oscilloscope so its rear is on the work surface
and the front of the oscilloscope facing you.
NOTE. All mounting screw holes are indicated by a star etched around the
mounting hole.
a. Remove the eleven T-15 Torx screws that secure the covers to the top
and both sides of the chassis.
b. Remove the seven T-15 Torx screws that secure the covers to the bottom
of the chassis.
c. Pull the bottom-right cover down and slide to the right to remove from
the oscilloscope. Pull the top-left cover upward and slide to the left to
remove from the oscilloscope.
CAUTION. Take care not to bind or snag the covers on the oscilloscope internal
cabling as you remove or install.
3. Reinstallation: Do in reverse steps a through c to reinstall the cabinet covers.
Covers
