Removal and Installation Procedures
6-- 44
TDS7104 & TDS7054 Service Manual
T--15 Torx
screw (4)
T--15 Torx
screw (2)
J510
NLX board
Riser
adapter
board
NLX support
bracket
Nut post (6)
Floppy
drive
cable
Hard drive
cable
connector
CD drive
cable
connector
Figure 6--26: Riser adapter and NLX board removal
