Specifications
TDS7104 & TDS7054 Service Manual
1-17
Table 1- 6: Input/output port specifications (Cont.)
Characteristic Description
Internal reference output
Frequency 10 M Hz 15 ppm over any ≥1 ms interval. Aging
<1 ppm per year
Output voltage V
out
high V
out
low (true)
≥2.5 V int o open circuit,
≥1.0 V into 50 Ω load
≤0.7 V wit h ≤4masink,
≤0.25 V into 50 Ω load
Rear-panel I/O ports Ports located on the rear panel
Parallel port (IEEE 1284) DB-25 connector, supports the following modes:
-standard (output only)
bidirectional (PS-2 compatible)
bidirectional enhanced parallel port (IEEE 1284
standard, mode 1 or mode 2, v 1.7)
-bidirecti onal high-speed extended capabilities
Audio ports Miniature phone jacks for stereo microphone input and
stereo l ine out put
USB port Allows connection or disconnection of USB keyboard
and/or m ouse whil e inst rument power is on
Keyboard port PS-2 compatible, instrument power must be off to make
connection
Mouse port PS-2 compat ible, inst rument power must be off to make
connection
LAN port RJ-45 connector, supports 10 base-T and 100 base-T
Serial port DB-9 COM1 port, uses NS16C550-compati ble UARTS,
transfer speeds up to 115.2 kb/s
SVGA video port Upper video port, DB-15 female connector, connect a
second m onitor t o use dual-monitor display mode,
supports Basi c requirements of PC99 specifications
GPIB port IEEE 488.2 standard interface
Scope VGA video port Lower video port, DB-15 female connector, 31.6 kHz
sync, EIA RS-343A compliant, connect to show the
instrument di splay, including live waveforms, on an
external monitor
