Performance Tests
TDS7104 & TDS7054 Service Manual
4-29
Table 4- 4: Test equipment (Cont.)
Item number and
description
PurposeExampleMinimum requirements
16. Adapter Female N-to-male BNC Tekt ronix part number
103-0058-00
Checking Analog Bandwidth
17. Adapter (three required) SMA female-to-female Tektronix part number
015-1012-00
Checking the del ay between
channels
18. Adapter (three required) SM A mal e-t o-female BNC Tektronix part number
015-1018-00
Checking the del ay between
channels
19. Pulse Generator 2 MHz, ≤150 ps rise time, 5 V out Fluke 9500B
1,2
UsedtoTestDeltaTime
Measurement Accuracy
20. Cable, Coaxial
(two required)
50 Ω, 20 in, male-to-male SMA
connectors
Tekt ronix part number
174-1427-00
UsedtoTestDeltaTime
Measurement Accuracy
21. Adapter SMA “T”, male to 2 SMA female Tekt ronix part number
015-1016-00
UsedtoTestDeltaTime
Measurement Accuracy
22. Adapter SMA fem ale t o BNC male Tekt ronix part number
015-0572-00
UsedtoTestDeltaTime
Measurement Accuracy
23. Adapter BNC male to female elbow Tektronix part number
103-0031-00
UsedtoTestDeltaTime
Measurement Accuracy
24. Termi nator Short circuit, SMA connector Tektronix part number
015-1021-00
UsedtoTestDeltaTime
Measurement Accuracy
25. Attenuator, 2X Ratio: 2X; im pedance 50 Ω; connec-
tors: female BNC input, male BNC
output
Tekt ronix part number
011-0069-02
UsedtoTestDeltaTime
Measurement Accuracy
1
Fluke 9500B/1100, 9500B/3200, or 9500B/2200 and an output head (9510, 9530, or 9560) appropriate for the bandwidth of
the oscilloscope being tested.
2
For Delta Time Measurement Accuracy, use a Flu ke 9500B or a pulse generator with a rise time as shown in Table 4- 9 on
page 4- 64.
3
P6139A probe is not appropriate for the TDS7104 oscilloscopes.
4
Warning: The P6243 and P6245 probes that may be used with this oscilloscope provide an extremely low loading
capacitance (<1 pF) to ensure the best possible signal reproduction. These probes should not be used to m easure
signals exceeding ±8 V, or errors in signal measurement will be observed. Above 40 V, damage to the probe may result.
To make measurements beyond ±8 V, use either the P6139A probe (good to 500 V), or refer to the catalog for a recom-
mended p robe. P6139A is not an appropriate probe for the TDS7104 oscilloscopes.
