Performance Tests
4-34
TDS7104 & TDS7054 Service Manual
TDS 7000 Test Record (Cont.)
Instrument Serial Number: Certificate Number:
Temperat ure: RH %:
Date of Calibration: Technician:
TDS7000 performance test MaximumOutgoingIncomingMinimum
Tri gger system accuracy
Time accuracy for pulse, glitch, timeout, and
Width, Hor. scale ≤ 1 s
Lower Limit
Upper Limit
3.5 ns
3.5 ns
__________
__________
__________
__________
6.5 ns
6.5 ns
Time accuracy for pulse, glitch, timeout, and
width, Hor. scale > 1 s
Lower Limit
Upper Limit
1.9 s
1.9 s
__________
__________
__________
__________
2.1 s
2.1 s
CH1 sensitivity, 50 MHz Pass/Fail __________ __________ Pass/Fail
CH1 delayed sensit ivity, 50 MHz Pass/Fail __________ __________ Pass/Fail
CH1 AUX trigger input, 50 MHz Pass/Fail __________ __________ Pass/Fail
CH1 sensitivity, full bandwidth Pass/Fail __________ __________ Pass/Fail
CH1 delayed sensit ivity, full bandwidth Pass/Fail __________ __________ Pass/Fail
CH1 AUX trigger input, 100 MHz Pass/Fail __________ __________ Pass/Fail
Output signal checks
Auxiliary trigger output, open circuit
High
Low
High ≥ 2.5 V __________
__________
__________
__________
Low ≤ 0.7 V
Auxiliary trigger output, 50 Ω
High
Low
High ≥ 1.0 V __________
__________
__________
__________
Low ≤ 0.25 V
Analog signal output, 1 MΩ p-p ≥ 80 mV __________ __________ p-p ≤ 120 mV
Analog signal output, 50 Ω p-p ≥ 44 mV __________ __________ p-p ≤ 66 mV
Probe compensat ion output si gnal
Frequency 950 Hz __________ __________ 1.050 kHz
Volt age (difference) 990 mV __________ __________ 1010 mV
