Installation
TDS5000 Series User Manual
1-17
Adjusting Display Contrast
If you find that the oscilloscope screen is too bright or too dark, use these steps
to adjust the LCD display contrast to your preference. You need to have a mouse
attached to perform this procedure.
If your instrument is using Windows ME, do the following steps:
1. Right click with the mouse on the Windows desktop.
2. Select Properties.
3. Select the Settings tab.
4. Click Advanced.
5. Select the Chips tab.
6. Click Gamma.
7. Adjust slider control for desired contrast.
8. Right click on the slider, and select Exit.
If your instrument is using Windows 2000, do the following steps:
1. Right click with the mouse on the Windows desktop.
2. Select Properties.
3. Select the Settings tab.
4. Click Advanced.
5. Select the Color tab.
6. Adjust slider control for desired gamma setting.
7. Click Apply.
8. Click OK.
Windows ME
Windows 2000
