TDS5000 Series User Manual
1-31
Accessories and Options
This section lists the product options, product upgrades, standard accessories,
and optional accessories that are available for the oscilloscope.
Options
You can order the options shown in Table 1--3 with the oscilloscope.
Table 1- 3: Instrument options
Hardware options
16 CD--RW drive (replaces CD--ROM drive)
17 Additional 256 MB of PC RAM
18 Touch-screen interface
1P Built--in thermal printer
Acquisition memory options
1M 2M/1M/500k on 1/2/4 channels (2M/1M on 1/2
channels on TDS5052)
2M 8M/4M/2M on 1/2/4 channels (8M/4M on 1/2
channels on TDS5052)
Mounting options
1K K420 oscilloscope cart with mouse accessory tray
1R Rackmount kit
Software options
2A Advanced analysis—equation editor, spectral FFT,
and histograms
DVD TDSDVD—Optical storage analysis software
J1 TDSJIT2—Jitter & timing analysis software
J2 TDSDDM2—Disk drive measurement s software
JT3 TDSJIT3—Jitter & timing analysis with Rj/Dj and
BER estimation
PWR TDSPWR2—Power analysis software
USB TDSUSBS—USB2.0 compliance test software only
Probe options
33 Add (1) P6158 3.0 GHz, 20x low capacitance probe
34 Add (1) P6247 1.0 GHz differential probe
