The LEDs for the Teldat 4Ge router are shown in Figure 6. The table below contains a description of them:
LEDs table
LED Status Description
LAN Tricolor Green -> connected. Blinking: con-
nection data activity
Amber -> blinking: auto-test
Red -> disconnected
PWR Monochrome green Device ON/OFF. This lights up when
connected to the power source.
W Tricolor Off -> system stopped
Red -> interface is unavailable be-
cause it is installing, it is not enabled
(shutdown) or due to auto-test failure
Yellow -> idle
• Rapid blinking. It has not registered
in the network or the quality is in-
sufficient.
• Slow blinking. GSM connection
(GPRS).
• Steady. WCDMA (UMTS/HSDPA)
connection.
Green -> connected. Blinking: con-
nection data activity.
3.2 Assembly
3.2.1 Mounting in rack
The Teldat 4Ge router cannot be mounted in a rack. However there are other types of mounting.
3.2.2 Standalone
The Teldat 4Ge router can be placed as a standalone device on a flat, stable surface.
You need to make sure that there is enough space around the router for ventilation purposes and that the electricity
cables can reach it.
3.2.3 Wall mounting
The Teldat 4Ge router can be mounted on the wall.
There are two slots on the underside of the device which are used to fix it to the wall. You can see this in section Un-
derside Panel on page 6.
We recommend the following accessories for wall mounting, valid for solid wall and Gypsum board (plaster) wall:
• 2 screws: [Coach Screw Head 90 Degrees. 3,5x30]
3 Components and Power Supply Teldat S.A.
8 Teldat 4Ge Router
