For more information about the LAN interface, please refer to:
- LAN connection on page 22
- LAN connector on page 36
- LAN interface on page 39
F POWER. Power connection.
The Regesta Smart PRO can be powered by either AC or DC power sources, depending on
the specific model.
For more information about the power connection options, please refer to:
- Power source on page 20.
- Power supply specifications on page 40
G 4xPort Gigabit Ethernet Switch (depending on the model)
For more information about the LAN interface, refer to:
- 4-port Ethernet switch connections on page 23
- LAN switch connector on page 37
- Switch interface on page 39
H DCE RS-232 serial ports or 2-4 wire RS-485/RS-422.
The hardware of each device (model) determines the configuration of ports.
For more information on the connector used for serial ports such as 2-4 wire RS-
485/RS-422 and DCE RS-232, please refer to:
RS232 option:
- RS-232 serial port on page 27
- RS-232 serial port connectors on page 38
- RS-232 serial interface on page 40
RS485 option
- RS-485/RS-422 serial port on page 27
- RS-485 serial port connectors on page 38
- RS-485 serial interface on page 40
I RF/WWAN antenna connectors for the Cellular interface (depending on the model).
For more information about the Cellular interface, please refer to:
- WWAN antenna connections (RF connectors) on page 24
- WWAN/RF connectors on page 37
- Wireless WAN interface on page 40
For more information about SIM installation for the Cellular interface, please refer to In-
stalling the SIM card on page 27 .
2 Product Overview Teldat S.A.
12 Regesta Smart PRO
