2.2. SYSTEM PCMCIA DUMP
Displays information on the status of the controller and the card.
The options are as follows:
Command Function
CIS-CARD Displays information contained the card CIS (Card Information Structure).
CIS-REG Displays information on how the card has been configured.
SOCKET-LIST Displays information on the detected PCMCIA controllers and the installed
cards.
SOCKET-STATE Displays information on how the SLOT PCMCIA controller has been
configured.
PCI Displays information on how the controller PCI registers have been
configured.
a) SYSTEM PCMCIA DUMP CIS-CARD
Displays information contained in the card CIS (Card Information Structure).
Example:
+system pcmcia dump cis-card
Slot[3-1]? 2
Socket 0: validate CIS: ok 20 tuples found
Tuple #1, offset 0x02, tuple_code 0x01, link_length 0x03
00 00 ff
dev_info NULL 0ns, 512b
Tuple #2, offset 0x07, tuple_code 0x17, link_length 0x03
00 00 ff
attr_dev_info NULL 0ns, 512b
Tuple #3, offset 0x0c, tuple_code 0x06, link_length 0x0b
02 00 4f 00 00 00 00 ce 00 00 00
mfc_long_link
function 0: attr 0x004f
function 1: attr 0x00ce
Tuple #4, offset 0x19, tuple_code 0x20, link_length 0x04
a4 00 af 1a
manfid 0x00a4, 0x1aaf
Tuple #5, offset 0x1f, tuple_code 0x15, link_length 0x2f
06 01 4e 6f 76 61 74 65 6c 20 57 69 72 65 6c 65
73 73 00 4d 65 72 6c 69 6e 20 55 4d 54 53 20 4d
6f 64 65 6d 00 4e 52 4d 36 38 33 31 00 00 ff
vers_1 6.1, "Novatel Wireless", "Merlin UMTS Modem", "NRM6831", ""
Tuple #6, offset 0x51, tuple_code 0x13, link_length 0x03
43 49 53
link_target
Tuple #7, offset 0x56, tuple_code 0x21, link_length 0x02
02 01
funcid serial_port [post]
Tuple #8, offset 0x5a, tuple_code 0x22, link_length 0x04
00 02 0f 7f
serial_interface
uart 16550 [space/mark/odd/even] [5/6/7/8] [1/1.5/2]
Tuple #9, offset 0x60, tuple_code 0x1a, link_length 0x06
05 05 00 04 63 02
config base 0x0400 mask 0x0263 last_index 0x05
Tuple #10, offset 0x68, tuple_code 0x1b, link_length 0x19
c7 01 99 69 55 1d f6 32 2d a3 60 f8 03 07 50 ff
ff 48 c1 05 43 4f 4d 31 00
cftable_entry 0x07 [default]
[audio]
Vcc Vnom 5V Istatic 15mA Ipeak 850mA Idown 25mA
io 0x03f8-0x03ff [lines=3] [8bit] [range]
TELDAT ROUTER– UMTS Monitoring
III - 29
Doc.DM757-I
Rev.10.60
