Tuple #22, offset 0x12a, tuple_code 0x1b, link_length 0x12
1f 98 a3 60 e8 03 07 50 ff ff 48 c1 05 43 4f 4d
39 00
cftable_entry 0x1f
[audio]
io 0x03e8-0x03ef [lines=3] [8bit] [range]
irq mask 0xffff [pulse]
7 bytes in subtuples
Tuple #23, offset 0x13e, tuple_code 0x1b, link_length 0x0e
27 98 23 50 ff ff 48 c1 05 43 4f 4d 79 00
cftable_entry 0x27
[audio]
io 0x0000-0x0007 [lines=3] [8bit]
irq mask 0xffff [pulse]
7 bytes in subtuples
+
b)
SYSTEM PCMCIA DUMP CIS-REG
Displays information on how the card has been configured.
Example:
+system pcmcia dump cis-reg 2
Socket 0 function 0:
Config register base = 0x0400, mask = 0x0263
Configuration option register [COR] = 0x47
[level_req] [func_ena] [addr_decode] [ireq_ena] [index = 00]
Card configuration and status register [CCSR] = 00
IO base = 0x03f8
IO size = 7
Socket 0 function 1:
Config register base = 0x0420, mask = 0x0263
read config register error
ATLAS-UMTS +
c)
SYSTEM PCMCIA DUMP SOCKET-LIST
Displays information on the detected PCMCIA controllers and installed cards.
Example:
+sys pcmcia dump socket-list
SLOT 3: CARDBUS controller type TI 1510 socket number 0
Card type detected Novatel Wireless Merlin UMTS Modem NRM6831 PC Card
product info: "Novatel Wireless", "Merlin UMTS Modem", "NRM6831", ""
manfid: 0x00a4, 0x1aaf
function: 2 (serial)
+
d)
SYSTEM PCMCIA DUMP SOCKET-STATE
Displays information on how the SLOT PCMCIA controller has been configured.
Example:
+system pcmcia dump socket-state
Identification and revision= *(0x00)=0x84
Chip information = *(0x1f)=0x00
PCMCIA Socket -0/A- Controller Registers
----------------------------------------------
Interface status = *(0x01)=0x7f: [bvd1/stschg] [bvd2/spkr] [detect]
[wrprot] [ready] [poweron]
TELDAT ROUTER– UMTS Monitoring
III - 31
Doc.DM757-I
Rev.10.60
