Power Monochrome
Green
Off -> not being powered through PSU.
On -> powered through PSU.
Alert Monochrome Green On -> when software is running.
USB Tricolor Off -> system is powered off.
Red -> interface is unavailable because it is installing, it is not en-
abled (shutdown) or due to auto-test failure.
Amber -> idle.
• Rapid blinking. It hasn’t registered in the network or the quality is
insufficient.
• Slow blinking. GSM connection (GPRS).
• Steady. WCDMA (UMTS / HSDPA) connection.
Green -> connected. Blinking: connection data activity.
Wi-Fi Bicolor Red -> interface down.
Green -> interface up.
Blinking (green/red) -> activity/maintenance.
DSL Monochrome
Green
Slow blinking -> not connected.
Rapid blinking -> the link is being established.
Steady -> connected.
Eth WAN Tricolor Green -> connected. Blinking: connection data activity.
Amber -> blinking, auto-test.
Red -> disconnected.
Cell Tricolor Off -> system is powered off.
Red -> interface is unavailable because it is installing, it is not en-
abled (shutdown) or due to auto-test failure.
Amber -> idle.
• Rapid blinking. It hasn’t registered in the network or the quality is
insufficient.
• Slow blinking. GSM connection (GPRS).
• Steady. WCDMA (UMTS / HSDPA) connection.
Green -> connected. Blinking: connection data activity.
Cobertura
(1, 2, 3, 4)
Monochrome blue Indicates the coverage level the 3G internal module has. 0 level (all
LEDs off) to 4 (all LEDs on).
3.2 Mounting in rack
The Teldat V router cannot be mounted in a rack. However, there are other types of mounting.
Teldat S.A.
3 Components and Power Supply
Teldat V Router 7
