Teldat TLDPV00A1 User Manual

A.3.4 WLAN/WiFi Connector (male)
PIN ANT
Internal
External
RF in/out
GND
A.3.5 DSL Connector
RJ11 DSL RJ11 PIN DSL
1
2
3
4
5
6
--
--
Line
Line
--
--
A.3.6 USB Connector
USB Type A PIN USB
1
2
3
4
Shell
VCC
DATA-
DATA+
GND
Shield
A.3.7 Configuration Connector
RJ45 CONFIGURATION RJ45 PIN CONF
1
2
3
4
5
6
7
8
--
RxD
GND
--
--
GND
TxD
--
Technical Information Teldat S.A.
30 Teldat V Router
