3.3 Plug-in Modules
The only module that can be inserted in the device is the USB 3G modem. To view the list of 3G modems supported,
please visit the following website: support@teldat.com
3.3.1 Installation
To install the USB modem, simply insert it in the USB slot located on the rear panel (as shown in the following fig-
ure):
Fig. 9: USB modem insertion slot
3.3.2 Uninstall
To remove the device, simply remove it from the slot where it was inserted. See Fig. 9 on page 10.
3.4 Power Source
The Teldat V router is powered though an external AC/DC.
Warning
The equipment must be used with the power supply provided by the manufacturer.
Workplace Conditions. Main Characteristics
• Avoid humid and or dusty locations.
• Direct exposure to sunlight, as well as other heat sources, should be avoided. The device should not be placed
amongst papers, magazines or other elements that could hinder natural air circulation.
• The device should not be placed very close to strong electromagnetic fields (such as speakers, engines, etc).
• Knocks and/or strong vibrations should be avoided during transport, operation and storage.
Warning
The electric current in power cables, telephone lines and communication cables is dangerous. To pre-
vent electric shocks, before installing, handling or opening the equipment covers, connect and discon-
nect the cables following the steps set forth in “ Connecting on page 11and “Disconnect on page 11 .
3.4.1 External Power Source
To connect the power supply to the device, please follow the steps set forth in “ Connecting on page 11.
To avoid electric shocks, residual current circulation and other unwanted effects, which also affect communications,
we recommend the following:
3 Components and Power Supply Teldat S.A.
10 Teldat V Router
