Chapter 6. Supplement
Independent COM Line
The new F21 crystal series provides the option of independent
(separate) COM lines for each model as below:
**F21-E1/E1B: 4 independent COM lines (Up/Down, East/West,
South/North and R0)
**F21-4D: 3 independent COM lines (Up/Down & U/D 2S, East/West
& E/W 2S and R0)
**F21-4S/4SB: 3 independent COM lines (Up/Down, East/West and
R0)
**F21-2D: 3 independent COM lines (Up 1S & 2S, Down 1S & 2S
and R0)
**F21-2S: 3 independent COM lines (Up, Down and R0)
Swapping COM & MAIN
According to the standard wiring diagram, all relays including the
MAIN relay will be turned off when the EMS is pressed. However, it
won’t work correctly when a pushbutton is programmed as a ”Toggle”
or “On/Off” function with “Bypass EMS”. Therefore, the MAIN and
COM must be swapped.
Changing R0/Start N.O. into N.C.
The N.O. (Normally Open) is a default output. If a N.C. (Normally
Closed) is necessary, to remove the wire No.11 (R0/Start, pink color)
and then insert it into the wire No.12 position on the wire cable
connector.
ID Code Remote Setting
ID Code Remote setting allows you to overwrite ID code of receiver
when Receiver or Transmitter is damaged. Before remote setting, one
must make sure both TX and RX are in same model and frequency
channel. By using remote setting, receiver ID code will be overwriting
by the transmitter.
Prior to remote setting, please follow the instruction below:
(a) Make sure both TX and RX are same model and in the same
frequency channel.
25
