Appendix C
Warranty/Repair Questionnaire
T200U/UP and M200EU/EUP
(06863C, DCN6371)
TELEDYNE API CUSTOMER SERVICE
EMAIL: api-customerservice@teledyne.com
PHONE: (858) 657-9800 TOLL FREE: (800) 324-5190 FAX: (858) 657-9816
C-1
CUSTOMER: ____________________________________ PHONE: ___________________________________________
CONTACT NAME: _______________________________ FAX NO. ___________________________________________
SITE ADDRESS: ______________________________________________________________________________________
MODEL SERIAL NO.: ____________________________ FIRMWARE REVISION: _______________________________
1. ARE THERE ANY FAILURE MESSAGES? ____________________________________________________________
_____________________________________________________________________________________________________
_____________________________________________________________________________________________________
PLEASE COMPLETE THE FOLLOWING TABLE: (NOTE: DEPENDING ON OPTIONS INSTALLED, NOT ALL TEST
PARAMETERS SHOWN BELOW WILL BE AVAILABLE IN YOUR INSTRUMENT)
*IF OPTION IS INSTALLED
PARAMETER RECORDED VALUE ACCEPTABLE VALUE
RANGE
PPB 5 PPB TO 2,000 PPB
NOx STAB
PPB
0.1 PPB WITH ZERO AIR
SAMPLE FLOW
CM
3
1,100 ± 110
OZONE FLOW
CM
3
80 ± 15
PMT SIGNAL WITH ZERO AIR
MV -20 TO 150
PMT SIGNAL AT SPAN GAS CONC
MV
PPB
0-5,000MV
0-2,000 PPB
NORM PMT SIGNAL AT SPAN GAS
CONC
MV
PPB
0-5,000MV
0-2,000PPB
PREREACT
MV -20 TO 150
HVPS
V 400 – 900
RCELL TEMP
ºC 40 ± 1
BOX TEMP
ºC AMBIENT ± 5ºC
PMT TEMP
ºC 5 ± 2ºC
MF TEMP
ºC 40 ± 1ºC
U/EU models only:
MOLY TEMP
ºC 315 ± 5ºC
UP/EUP models only:
O3KL TEMP
ºC 200 ± 5ºC
RCEL PRESS
IN-HG-A <4” (CONSTANT)
SAMP PRESS
IN-HG-A ~ 1-5” < AMBIENT (CONSTANT)
NOx SLOPE
1.0 ± 0.3
NOx OFFSET
-50 TO 50
NO SLOPE
1.0 ± 0.3
NO OFFSET
-50 TO 50
ETEST
PMT MV 2000 ± 1000
OTEST
PMT MV 2000 ± 1000
In the CAL>CONC>CONV menu:
NO2A (value input for low NO
2
cal)
SETA (CE for low NO
2
) Should be >0.4 of NO2A
NO2B (value input for high NO
2
cal)
SETB (CE for NO
2
cal) Should be >0.4 of NO2B
