INSTRUMENT MANUAL
VACUUM GAUGE MODEL MM200
160Phone:(215) 947-2500 fax:(215) 947-7464 e-mail:sales@televac.com web site:www.televac.com
MM-200_im REV M
Page 3 of 160
SECTION TITLE PAGE
300 INSTALLATION 18
301 MODULE CONFIGURATION 18
302 LINE VOLTAGE SELECTION 23
303 GAUGE CONTROLLER INSTALLATION 23
Freestanding 23
Rack Mounted 23
304 GAUGE SENSOR INSTALLATION WARNINGS 24
305 VACUUM CONNECTION FITTINGS 25
NPT Pipe Thread Connections 25
0-ring Compression Fittings 25
Conflat Flange Fittings 25
KF Flange Connections 26
Cajon Fittings 26
306 GAUGE SENSOR INSTALLATION 26
307 REMOVAL AND INSTALLATION OF MODULES 27
308 DESCRIPTION OF MODULES 28
Power Supply Module 28
Setpoint Relay Module 29
Communications Module 29
Thermocouple Module 30
Convection Module 31
Diaphragm Module 31
Cold Cathode Module 32
3D Hot Cathode Resident Module (I² R Degas) 32
3E Hot Cathode Resident Module (EB Degas) 34
3F Hot Cathode Mini BA Module (software ver. 2.31 or higher) 35
Capacitance Diaphragm Modules 38
