INSTRUMENT MANUAL
VACUUM GAUGE MODEL MM200
160Phone:(215) 947-2500 fax:(215) 947-7464 e-mail:sales@televac.com web site:www.televac.com
MM-200_im REV M
Page 57 of 160
1b. COLD CATHODE SETUP (For Software Version 1.30
(1)
and higher)
Power ON. Displays software version, does self-diagnostics. If
everything is all right and the pressure is below 10 microns (e.g. "0")
the display is as follows (assumes CC is station 5, TC is station 1):
ACTION - Push DISPLAY (See Table of Display Descriptions)
1. SOFT 1.30 is displayed….. then
2. Ccion Auto Ccion SELF (3)
Ccion both (4)
3. HP 5 OFF HP 5 rdy (5)
4. 1.2-9 51 0
NOTES:
(1) Required for 7F module 2-6200-245
(2) Will skip to display of step 4 if in Auto mode
(default setting for software 1.33 and higher)
(3) HP = High Potential (voltage)
(4) If turned off by overpressure, the CC must be reset by the front
panel or by RS232.
(5) CC display will come on if TC is below 10 microns ( Go to step 4)
(6) Error codes which may be displayed:
Shut dn = Unit was shut down overpressure safety
To Next Page
