Local Network- Possibility to change lan and guest configuration: IP address / subnet and
shared IP address ranges. If necessary, disable the DHCP server. Static IP-MAC address
associations (Add new static lease) can also be described
Devices - provides a list of all devices connected to the local network
WAN Services Not in use for Trådløst Bredbånd
Firewall - there are options: change the firewall level, enable / disable ping
Diagnostics - ability to perform router and network diagnostics
Sharing Not in use for Trådløst Bredbånd
Parental Controls - Ability to block / allow WEB pages (Parental Control), restrict LAN
devices' access to the Internet on certain days and hours of the week in 15 minute
increments (Access Control)
VPN Server Not in use for Trådløst bredbånd
DMZ Not in use for Trådløst Bredbånd
ETH Linespeed - to control the physical speed of WAN and LAN ports (Auto / 100 Mb/s)
5 RESTORE FACTORY SETTINGS
This feature is on the System Info tab in the Configuration section.
6 CHANGE WIRELESS SETTINGS
Note. If you were able to connect successfully over the wireless connection
and the connection is working properly, we recommend that you do not
change the settings. Settings should only be changed if necessary.
Click the Wireless tab to view and / or change WiFi settings
On the left side of the window, select the area you want to view / change; In
the configuration window you can control:
a) Radio
b) AP
c) WPS

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Telia F1 and is the answer not in the manual?

Telia F1 Specifications

General IconGeneral
WirelessYes
FirewallYes
BrandTelia
ModelF1
Wi-Fi Standards802.11ac
Frequency Band2.4 GHz, 5 GHz
Ethernet Ports4
WAN Ports1
USB Ports1
Security FeaturesWPA2
